Pigment yellow 110-Corimax Yellow 2RL

Product parameter list

Color Index No.Pigment yellow 110
Product nameCorimax Yellow 2RL
Product categoryOrganic Pigment
Light Fastness(coating)7-8
Heat Resistance(coating)200
Light Fastness(plastic)7-8
Heat Resistance(plastic)280
Color
Pigment-yellow-110-Color
Hue distribution

Features: Corimax Yellow 2RL is a greenish yellow pigment,high transparency.
Application:
Recommended for automotive paints, architectural paints, industrial paints, powder coatings, printing pastes, PVC, rubber, PS, PP, PE, PU, water based inks, solvent inks, UV inks.
Can be used for coil coating, offset ink.
—————————————————————————————————————————————————————————————————

Chinese name: Pigment Yellow 110
Chinese alias: Fischertoken Yellow GR; Pigment Yellow 110;
English name: Pigment Yellow 110
English alias: 56280; CI Pigment Yellow 110; 1H-Isoindol-1-one, 3,3 '-(1,4-phenylenedinitrilo) bis (4,5,6,7-tetrachloro-2,3-dihydro-3, 3 '-(benzene-1,4-diyldiimino) bis (4,5,6,7-tetrachloro-1H-isoindol-1-one)
CAS: 5590-18-1
EINECS: 226-999-5
Molecular formula: C22H6Cl8N4O2
Molecular weight: 641.9326
InChI: InChI = 1 / C22H6Cl8N4O2 / c23-11-7-9 (13 (25) 17 (29) 15 (11) 27) 21 (35) 33-19 (7) 31-5-1-2-6 ( 4-3-5) 32-20-8-10 (22 (36) 34-20) 14 (26) 18 (30) 16 (28) 12 (8) 24 / h1-4H, (H, 31,33 , 35) (H, 32, 34, 36)

Molecular Structure:

Density: 1.93g / cm3
Boiling point: 808.6 ° C at 760 mmHg
Flash point: 442.8 ° C
Vapor pressure: 3.37E-26mmHg at 25 ° C

Physical and chemical properties:

Hue or light: red light yellow
Density / (g / cm3): 1.82
Bulk density / (lb / gal): 15.1
Melting point / ℃: 300
Specific surface area / (m2 / g): 26 (3RLTN)
pH value / (10% slurry): 6.5-8.7
Oil absorption / (g / 100g): 36-77
Covering power: transparent type

Product Usage:

The pigment yellow 110 gave a strong red light yellow. Among them, the specific surface area of Irgazin Yellow 2RLT is 56m2 / g, and its light fastness, weather fastness, heat resistance and migration resistance are excellent, which makes it widely used. Mainly used in metal decorative paints, automotive coatings and latex paints; shows excellent thermal stability in plastic coloring (soft PVC can withstand 200 ℃ / 30min), light fastness (grade 7-8 under 1 / 25SD) Known as one of the most lightfast varieties of yellow organic pigments; heat resistance up to 290 ℃ in HDPE (1 / 3SD); suitable for the coloring of virgin pulp of polypropylene, polyacrylonitrile and polyamide; also used in various printing inks, good Solvent resistance, heat resistance and sterilization resistance; art pigments, solvent-based wood coloring, etc.
